19" 1U HD Patch Panel 48-Port, black, empty (R512721)

19" 1U HD Patch Panel 48-Port, black, empty (R512721)

Metal patch panel with integrated cable tieshelf. Ready for all HD inserts (copper / FO).

Артикул: R512721 Категорія:

Scope of supply

  • 19" 1U HD patch panel

  • 19" mounting kit

  • 4 velcro strips

  • Installation instructions

Mechanical Data

Dimensions

482.6 mm x 43.2 mm x 225.0 mm / 19 in x 1.701 in x 8.858 in (W x H x D)

Color

steel, blue, chromatized / front, black (RAL 9005)

Material

steel: DC01 (1.0330), 1.5 mm

Technical Data

Amount of height units

1 U

Rack mounting version

sub-rack

Assembly

empty

Capacity (ports)

24 / 48

Standard

UL Listed

Amount of height units

1

Fastening

19 "

Modular patch panel with integrated cable tie shelf, accommodating up to four connection module holders HD Panel, installation-friendly thanks to snap-and-go technique, featuring a complete grounding system and optional blind covers. Designed to accommodate the R&M HD security system, with its 2-level protection concept: color coding, locking option or automated infrastructure management systems. Optional labeling strips, fastening kit, integrated port numbering, tool-free locking and unlocking system. Automatic ground contacting by spring contacts. Sub-rack material sheet steel, colorless chromatized, side panels plastic (PC), halogen-free, color black (RAL 9005).

With a capacity of up to 48 shielded or unshielded RJ45 connection modules of Cat. 6
A
ISO, for the setting up of transmission channels of Class E
Awith up to 4 plugged connections.

Інструкції з встановлення

Завантажити
