Breakout Cable SC PC 24x - SC PC 24x, beige, OM3, Bm/3, 20 m (R502237)

Breakout Cable SC PC 24x - SC PC 24x, beige, OM3, Bm/3, 20 m (R502237)

Breakout Cable SC PC 24x - SC PC 24x, beige, OM3, Bm/3, 20 m (R502237)

Both sides fitted with 24 SC PC connector.

Connector color: beige.

Fiber: MM G50/125 (OM3).

Cable: Breakout 24-fibers, Ø 14.5 mm, turquoise.

Fan-out legs of 1.0 m length (on both sides).

Артикул: R502237 Категорія:
Mechanical Data

Color

turquoise/aqua

Cable length

20 m

Technical Data

Conductor type FO

tight buffer

Fiber type

Multimode (MM)

Fiber class

OM3

Fiber diameter

G50 / 125 µm

Number of connectors (A)

24

Number of connectors (B)

24

Cable type

Breakout cable

Cable design

I-V(ZN)HH

Jacket material

LSZH

Cable jacket characteristics

Cable, metal-free

zero-halogen

Cable overall diameter

Ø 14.5 mm

Connector type (A)

SC

Connector type (B)

SC

Fiber Count

24

Connector color (A)

beige

Connector color (B)

beige

Polishing plug (A)

PC

Polishing plug (B)

PC

Protection class IP (A)

IP 20

Protection class IP (B)

IP 20

Return loss grade RL (A)

3

Return loss grade RL (B)

3

Attenuation grade IL (A)

Bm

Attenuation grade IL (B)

Bm

Connector class

connector
