| Dimensions | 35.0 mm x 129.0 mm x 215.0 mm / 1.378 in x 5.079 in x 8.465 in (W x H x D) |
| Color Code RAL | 9005 Jet black |
| Conductor type FO | semi-tight buffer, dry |
| Fiber type | Multimode (MM) |
| Fiber class | OM4 |
| Fiber diameter | G50 / 125 µm |
| Number of connectors (A) | 2 |
| Number of connectors (B) | 12 |
| Connector type (A) | MPO, female |
| Connector type (B) | LC-Duplex |
| Connector color (A) | gray |
| Connector color (B) | heather violet |
| Polishing plug (A) | PC |
| Polishing plug (B) | PC |
| Protection class IP (A) | IP 20 |
| Protection class IP (B) | IP 20 |
| Return loss grade RL (A) | 4 |
| Return loss grade RL (B) | 3 |
| Attenuation grade IL (A) | Cm |
| Wiring diagram | type S+ |
| Rack mounting version | slide-in unit |
| Adapter fastening method | end cap snap-in |
| Assembly | fully populated |
| Sleeve material | ceramic |
| Standard | MPO connectors acc. to IEC 61754-7-1 (MPO connector family - one fiber row) |
