Slide-in unit,
labeling strips
installation instructions
Dimensions | 80.0 mm x 105.0 mm x 30.0 mm / 3.15 in x 4.134 in x 1.181 in (W x H x D) |
Color Code RAL | 7000 Squirrel gray |
Material | plastic: PC, fiber-glass reinforced, halogen-free |
Conductor type FO | semi-tight buffer, dry |
Fiber type | Multimode (MM) |
Fiber class | OM4 |
Fiber diameter | G50 / 125 µm |
Number of connectors (A) | 3 |
Connector type (A) | MPO, female |
Connector color (A) | black |
Polishing plug (A) | PC |
Return loss (RL) | ≥ 35 dB |
Insertion loss (IL) max. value | ≤ 0.3 dB |
Wiring diagram | type S+ |
Rack mounting version | slide-in unit |
Adapter fastening method | end cap snap-in |
Assembly | fully populated |
Capacity (ports) | 18 |
Standard | MPO connectors acc. to IEC 61754-7-1 (MPO connector family - one fiber row) |
