o High bandwidth patching of 40G and 100G Ethernet transmission
o Quick-Release for easy handling
o Boot color indicating polarity
o MPO-Elite guaranteeing high optical performance
o Low smoke zero halogen rated jacket material
o Bend-insensitive fiber for multi- and singlemode
o Factory terminated and tested
| DESCRIPTION | VALUE/VALUE RANGE |
|---|---|
| Number of connectors (A) | 1 |
| Number of connectors (B) | 1 |
| Cable overall diameter | 3.0mm |
| Connector type (A) | MPO |
| Connector color (A) | heather violet |
| Connector type (B) | MPO |
| Connector color (B) | heather violet |
| Fiber type | OM4 |
| Fiber class | OM4 |
| Fiber diameter | G50 / 125 µm |
| Insertion loss (IL) max. value | 0.3 dB |
| Return loss (RL) | 35 dB |
| DESCRIPTION | VALUE/VALUE RANGE |
|---|---|
| Operation temperature | +15 °C to +55 °C / +59 °F to +131 °F |
| Transport / store temperature | -20 °C to +60 °C / -4 °F to +140 °F |
