Cable assyembly FO, MPO-QR Female with 12 fibers Grade C PC/UPC Without -MPO-QR Female with 12 fibers, Grade CPC/UPC, Without, 12xMultimode OM3 (G50), Turquoise ECA (LSZH), 3m (R869836)

Name: Cable assyembly FO, MPO-QR Female with 12 fibers Grade C PC/UPC Without -MPO-QR Female with 12 fibers, Grade CPC/UPC, Without, 12xMultimode OM3 (G50), Turquoise ECA (LSZH), 3m (R869836) - ДП "Сінергія"
SKU: R869836

Cable assyembly FO, MPO-QR Female with 12 fibers Grade C PC/UPC Without -MPO-QR Female with 12 fibers, Grade CPC/UPC, Without, 12xMultimode OM3 (G50), Turquoise ECA (LSZH), 3m (R869836)

Fiber: SM E9/125 G.657.A2 (OS1, OS2)

Артикул: R869836 Категорія: Misc

Environmental Characteristics

Operation temperature	+15 °C to +55 °C / +59 °F to +131 °F
Transport / store temperature	-20 °C to +60 °C / -4 °F to +140 °F

Technical Data

Fiber type	OM3
Fiber class	OM3
Fiber diameter	G50 / 125 µm
Number of connectors (A)	1
Number of connectors (B)	1
Cable type	MiniCore cable
Cable design	normal
Jacket material	LSFH
Cable overall diameter	3.0mm
Connector type (A)	MPO-QR female
Connector type (B)	MPO-QR female
Connector color (A)	black
Connector color (B)	black
Color (B1)	turquoise/aqua
Return loss (RL)	≥ 35 dB
Insertion loss (IL) max. value	≤ 0.3 dB
Attenuation grade IL (A)	0.3dB
Attenuation grade IL (B)	0.3dB
