Patch Cord 12-Fiber MPO-QR female – MPO-QR female, turquoise, OM3, type B polarity, 3m (R869838)

Patch Cord 12-Fiber MPO-QR female – MPO-QR female, turquoise, OM3, type B polarity, 3m (R869838)

Patch Cord 12-Fiber MPO-QR female – MPO-QR female, turquoise, OM3, type B polarity, 3m (R869838)

Артикул: R869838 Категорія:

o High bandwidth patching of 40G and 100G Ethernet transmission

o Quick-Release for easy handling

o Boot color indicating polarity

o MPO-Elite guaranteeing high optical performance

o Low smoke zero halogen rated jacket material

o Bend-insensitive fiber for multi- and singlemode

o Factory terminated and tested

Technical Data

DESCRIPTIONVALUE/VALUE RANGE
Number of connectors (A)1
Number of connectors (B)1
Cable overall diameter3.0mm
Connector type (A)

MPO

Connector color (A)

turquoise/aqua

Connector type (B)

MPO

Connector color (B)

turquoise/aqua

Fiber type

OM3

Fiber class

OM3

Fiber diameter

G50 / 125 µm

Insertion loss (IL) max. value0.3 dB
Return loss (RL)35 dB

Climatic Data

DESCRIPTIONVALUE/VALUE RANGE
Operation temperature+15 °C to +55 °C / +59 °F to +131 °F
Transport / store temperature-20 °C to +60 °C / -4 °F to +140 °F
