Patch cord FO, E-2000-Simplex PC/UPC Grade C - E-2000-Simplex PC/UPC Grade C, Singlemode OS2 G.657.A2, Simplex 3.0mm, Eca (LSZH), 1m (R889154)

Name: Patch cord FO, E-2000-Simplex PC/UPC Grade C - E-2000-Simplex PC/UPC Grade C, Singlemode OS2 G.657.A2, Simplex 3.0mm, Eca (LSZH), 1m (R889154) - ДП "Сінергія"
SKU: R889154

Patch cord FO, E-2000-Simplex PC/UPC Grade C - E-2000-Simplex PC/UPC Grade C, Singlemode OS2 G.657.A2, Simplex 3.0mm, Eca (LSZH), 1m (R889154)

Both sides fitted with one E-2000™ PC / UPCconnector

Connector color: blue

Lever color: blue

Артикул: R889154 Категорія: E-2000™

Mechanical Data

Color	yellow
Cable length	1 m

Technical Data

Patch cord type	simplex
Conductor type FO	tight buffer
Fiber type	Singlemode (SM)
Fiber class	G.657.A2 (covers G.652.D, G.657.A1+B2, OS1, OS2)
Fiber diameter	n.a.
Number of connectors (A)	1
Number of connectors (B)	1
Cable type	Patch cord, polarity A-A
Cable design	Single Jacket
Jacket material	LSZH
Cable jacket characteristics	Cable, metal-free zero-halogen flame retardant
Cable overall diameter	Ø 3.0 mm (±0.15)
Connector type (A)	E-2000™
Connector type (B)	E-2000™
Connector color (A)	blue
Connector color (B)	blue
Lever- / frame-coding (A)	Color
Lever color (A)	blue
Lever- / frame-coding (B)	Color
Lever color (B)	blue
Polishing plug (A)	PC
Polishing plug (B)	PC
Protection class IP (A)	IP 20
Protection class IP (B)	IP 20
Return loss grade RL (A)	2
Return loss grade RL (B)	2
Attenuation grade IL (A)	C
Attenuation grade IL (B)	C
Connector class	connector
CPR classification	Eca
Standard	acc. to DIN EN 186270 acc. to IEC 61754-15
