Fitted with one SC-Duplex PC and one SC-RJ PC connector.
Connector color SC-Duplex: beige.
Connector color SC-RJ: black.
Clip color SC-RJ: black.
Fiber: MM G62.5/125 (OM1).
Cable: F8 2.7x5.5 mm, orange.
| DESCRIPTION | VALUE/VALUE RANGE |
|---|---|
| Protection class IP |
IP 20 |
| Connector class |
connector |
| Protection class IP (A) |
IP 20 |
| Number of connectors (A) | 1 |
| Protection class IP (B) |
IP 20 |
| Number of connectors (B) | 1 |
| Cable type |
Patch cord, polarity A-B |
| Jacket material |
LSZH |
| Cable jacket characteristics |
Flame-retardant |
| Cable overall diameter | F8 2.7 x 5.5 mm (±0.15) |
| Connector type (A) |
SC-Duplex |
| Polishing plug (A) |
PC |
| Attenuation grade IL (A) | Bm |
| Return loss grade RL (A) | 3 |
| Connector color (A) |
beige |
| Lever color (A) |
black |
| Connector type (B) |
SC-RJ |
| Polishing plug (B) |
PC |
| Attenuation grade IL (B) | Bm |
| Return loss grade RL (B) | 3 |
| Connector color (B) |
black |
| Lever- / frame-coding (B) |
Color |
| Lever color (B) |
black |
| Fiber type |
multimode (MM) |
| Fiber class |
OM1 |
| Conductor type |
tight buffer |
| Fiber diameter |
G62.5 / 125 µm |
| Patch cord type |
duplex figure 8 |
| DESCRIPTION | VALUE/VALUE RANGE |
|---|---|
| Cable length | 2.0 m / 6 ft 7 in |
| Color |
orange |
