Compact design (SFF). 1.25 mm ferrule technology. Locking type latched push-pull.
Semi-tight buffer Ø 0.9 mmone side fitted with LC connector
Pigtail with semi-tight buffer PA/PBT, Ø 0.9 mm, pink, singlemode G.652.D/G.657.A1 9/125 µm (OS1, OS2), length 2.5 m. Fitted with one LC connector in acc. with IEC 61754-20. Zirconia (ceramic) ferrule with an angled polish APC 8° endface geometry, connectors tuned in accordance with IEC 61755-3-2 and qualifiedin acc. with IEC 61753-1 for category U (uncontrolled environment). Green connector housing (singlemode), material PEI / UL 94 V-0,green strain relief and white plastic dust cover.
Optical specifications (random mated):
Performance acc. to IEC 61753-1 (Table A.12):
Insertion loss (IL) Grade A for 97% of the tested specimen: = 0.15 dB / typical = 0.07 dB
Return loss (RL) Grade 1: = 80 dB
Mechanical specifications:
Mating cycles: delta IL < 0.2 dB after 500 mating cycles
Pull-out force fiber pigtail: = 5 N
