The solution for aerial applications. The cavities in between the loose tubes are filled with gel, ensuring water-blocking performance. Span lengths of 250 meters and more are possible, also thanks to a swelling tape and aramide yarns underneath the outer sheath.
Sheath: PE, black.
Fiber: multimode (MM) G50/125.
| DESCRIPTION | VALUE/VALUE RANGE |
|---|---|
| Standard / norm |
IEC 60794-1-2 E1 IEC 60794-1-2 E11 IEC 60794-1-2 E3 IEC 60794-1-2 F1 IEC 60794-1-2 E4 IEC 60794-1-2 E7 IEC 60794-1-2 F5 |
| Jacket material |
PE |
| CPR classification | Eca |
| Cable jacket characteristics |
Cable, water-tight |
| Cable overall diameter | 18.5 mm |
| Cable design |
A-DF(ZN)2YQ(ZN)2Y |
| Stranding |
8 x 12 pairs |
| Fiber type |
multimode (MM) |
| Fiber class |
OM2 |
| Fiber Count | 96 |
| Conductor type |
loose tube, gel-filled |
| Fiber diameter |
G50 / 125 µm |
| DESCRIPTION | VALUE/VALUE RANGE |
|---|---|
| Cable length | 2000.0 m / 6562 ft |
| Color |
black |
