The solution for installations directly in the ground in difficult environments. The cable features an inner and an outer PE sheath. The cavities between the stranded gel-filled loose tubes are filled with gel, also ensuring water tightness. Underneath the outer sheath the cable is surrounded by an 0.155 mm corrugated steel armor (ECCS).
Sheath: PE, black
Fiber: singlemode (SM) E9/125
DESCRIPTION | VALUE/VALUE RANGE |
---|---|
Standard / norm | ISO/IEC 11801:2002 ITU-T G.652.D IEC 60794-1-2 E1 IEC 60794-1-2 E11 IEC 60794-1-2 E3 IEC 60794-1-2 F1 IEC 60794-1-2 E4 IEC 60794-1-2 E7 |
Jacket material | PE |
CPR classification | Fca |
Cable jacket characteristics | Cable, water-tight |
Armour | Steel-armored |
Cable overall diameter | 14.5 mm |
Cable design | A-DF(ZN)2YW2Y |
Stranding | 1 x 12 pairs |
Fiber type | singlemode (SM) |
Fiber class | G.652.D + G.657.A1 (OS1, OS2) |
Fiber Count | 12 |
Conductor type | loose tube, gel-filled |
Fiber diameter | E9 / 125 µm |
Standard put-up length on drum | 2100 m ± 5% |
DESCRIPTION | VALUE/VALUE RANGE |
---|---|
Cable length | 2000.0 m / 6562 ft |
Color | black |
