Stranded Loose Tube Cable A-DF(ZN)2YW2Y, G.652.D, Eca, 8x12-fibers (R314559)

Stranded Loose Tube Cable A-DF(ZN)2YW2Y, G.652.D, Eca, 8x12-fibers (R314559)

Stranded Loose Tube Cable A-DF(ZN)2YW2Y, G.652.D, Eca, 8x12-fibers (R314559)

The solution for installations directly in the ground in difficult environments. The cable features an inner and an outer PE sheath. The cavities between the stranded gel-filled loose tubes are filled with gel, also ensuring water tightness. Underneath the outer sheath the cable is surrounded by an 0.155 mm corrugated steel armor (ECCS).

  • Sheath: PE, black

  • Fiber: singlemode (SM) E9/125

Артикул: R314559 Категорія:

Technical Data

DESCRIPTIONVALUE/VALUE RANGE
Standard / norm

ISO/IEC 11801:2002

ITU-T G.652.D

IEC 60794-1-2 E1

IEC 60794-1-2 E11

IEC 60794-1-2 E3

IEC 60794-1-2 F1

IEC 60794-1-2 E4

IEC 60794-1-2 E7

Cable type

Stranded loose tube cable

Jacket material

PE

CPR classificationFca
Cable jacket characteristics

Cable, water-tight

Armour

Steel-armored

Cable overall diameter16.0 mm
Stranding

8 x 12 pairs

Fiber type

G.652.D

Fiber Count96
Conductor type

loose tube, gel-filled

Fiber diameter

E9 / 125 µm

Application

outdoor-use

DIN/VDE CodeA-DF(ZN)2YW2Y
Standard put-up length on drum2100 m ± 5%

Mechanical Data

DESCRIPTIONVALUE/VALUE RANGE
Cable length2000.0 m / 6562 ft
Color

black
