The solution for high fiber-count links within buildings. The cable's compact construction of stranded gel-filled loose tubes, the blocking swelling tape for water tightness, and most of all its excellent mechanical properties make it the perfect choice.
Sheath: LSZH, green.
Fiber: multimode (MM) G50/125.
| DESCRIPTION | VALUE/VALUE RANGE |
|---|---|
| Standard / norm |
IEC 60794-1-2 E11 IEC 60794-1-2 E3 IEC 60794-1-2 F1 IEC 60332-1 IEC 60332-3C IEC 61034 IEC 60754-2 ISO/IEC 11801:2002 |
| Jacket material |
LSZH |
| CPR classification | Eca |
| Cable jacket characteristics |
Cable, metal-free Zero-halogen |
| Armour |
Rodent protection |
| Cable overall diameter | 11.0 mm |
| Cable design |
U-DQ(ZN)BH |
| Stranding |
6 x 12 pairs |
| Fiber type |
multimode (MM) |
| Fiber class |
OM2 |
| Fiber Count | 72 |
| Conductor type |
loose tube, gel-filled |
| Fiber diameter |
G50 / 125 µm |
| Standard put-up length on drum | 2100 m ± 5% |
| DESCRIPTION | VALUE/VALUE RANGE |
|---|---|
| Cable length | 2000.0 m / 6562 ft |
| Color |
green |
