Name: Stranded loose tube cable, outdoor-use, CSTA-steel tape armour, HDPE sheath - black, 16x12-fibers OM4 (R857115) - ДП "Сінергія"
SKU: R857115

Environmental Characteristics

Operation temperature	-40 °C to +70 °C / -40 °F to +158 °F
Temperature cycling acceptance criteria	Δα ≤ 0,05 dB
Temperature cycling	-40 °C +70 °C / -40 °F +158 °F
Temperature cycling test method	IEC 60794-1-22:F1
Transport / store temperature	-40 °C to +70 °C / -40 °F to +158 °F

Mechanical Data

Crush resistance - short term	5000 N/100mm
Expected lifetime	min. 30 years
Tensile performance - during installation	3500 N
Tensile performance - during installation acceptance criteria	Δα ≤ 0,05 dB after test
Tensile Performance during Installation TestMethod	IEC 60794-1-21:E1
Repeated bending acceptance criteria	no damage
Repeated bending test method	IEC 60794-1-21:E6
Repeated bending	R=20 x cable diameter, 25 cycles
Cable bend - acceptance criteria	Δα ≤ 0,05 dB after test, no damage
Torsion	L = 1 m, rotation angle ±180°, 10 cycles
Torsion acceptance criteria	no damage
Impact resistance acceptance criteria	Δα ≤ 0,05 dB after test, no damage
Torsion test method	IEC 60794-1-21:E7
Impact resistance	20 Nm, 3 impacts, d=20 mm, R=300 mm
Crush resistance - long term acceptance criteria	Δα ≤ 0,05 dB prior release, no damage
Tensile performance - in service acceptance criteria	Δα ≤ 0,05 dB
Tensile performance - in service test method	IEC 60794-1-21:E1
Tensile performance - in service	1100 N
Cable weight	185.0 kg/km / 124 lbs/1000ft

Technical Data

Fiber type	OM4
Cable type	Stranded loose tube cable
Jacket material	UV stable HDPE
Fiber Count	192
CPR classification	Fca
Armour	Corrugated steel tape armoured (CSTA)
Fiber color coding	1.-12.: red, green, blue, yellow, white, grey, brown, violet, turquoise, black, orange, pink
Sheath marking	Ink-Jet, white
Standard put-up length on drum	4100 m ± 5%
FRP/coat. CSM nominal thickness [mm]	1.7
Cable version	n.a.
Application	outdoor use
Loose tube diameter [mm]	1.7
