VARIOline E-2000™ APC 12x - E-2000™ APC 12x, green/green, G.652.D, C/1, indoor, 3U, 40 m (R806364)
VARIOline E-2000™ APC 12x - E-2000™ APC 12x, green/green, G.652.D, C/1, indoor, 3U, 40 m (R806364)
Both sides fitted with E-2000™ APC 8° connectors. Pulling tube (IP67) included.
Connector color: green.
Fiber: SM E9/125 G.652.D/G.657.A1 (OS1, OS2).
Fan-out length: 735 mm (3U)
Technical Data
| DESCRIPTION |
VALUE/VALUE RANGE |
| Protection class IP |
IP 20
IP 54 (correlates to NEMA 3S)
|
| Connector class |
connector
|
| Protection class IP (A) |
IP 20
|
| Number of connectors (A) |
12 |
| Protection class IP (B) |
IP 20
|
| Number of connectors (B) |
12 |
| Cable type |
VARIOline cable
|
| Jacket material |
LSZH
|
| Cable jacket characteristics |
Cable, water-tight
Cable, metal-free
Zero-halogen
|
| Cable overall diameter |
6.5 mm |
| Connector type (A) |
E-2000™
|
| Polishing plug (A) |
APC 8°
|
| Attenuation grade IL (A) |
C |
| Return loss grade RL (A) |
1 |
| Connector color (A) |
green
|
| Lever- / frame-coding (A) |
Color
|
| Lever color (A) |
green
|
| Connector type (B) |
E-2000™
|
| Polishing plug (B) |
APC 8°
|
| Attenuation grade IL (B) |
C |
| Return loss grade RL (B) |
1 |
| Connector color (B) |
green
|
| Lever- / frame-coding (B) |
Color
|
| Lever color (B) |
green
|
| Fiber type |
singlemode (SM)
|
| Fiber class |
G.652.D + G.657.A1 (OS1, OS2)
|
| Fiber Count |
12 |
| Conductor type |
loose tube, gel-filled
|
| Fiber diameter |
E9 / 125 µm
|
Mechanical Data
| DESCRIPTION |
VALUE/VALUE RANGE |
| Cable length |
40.0 m / 131 ft |
| Color |
green
|
