Both sides fitted with SC PC connectors. Pulling tube (IP67) included.
Connector color: beige.
Fiber: MM G50/125 OM3.
Fan-out length: 735 mm (3U)
| DESCRIPTION | VALUE/VALUE RANGE |
|---|---|
| Protection class IP |
IP 20 IP 54 (correlates to NEMA 3S) |
| Connector class |
connector |
| Protection class IP (A) |
IP 20 |
| Number of connectors (A) | 12 |
| Protection class IP (B) |
IP 20 |
| Number of connectors (B) | 12 |
| Cable type |
VARIOline cable |
| Jacket material |
LLDPE |
| Cable jacket characteristics |
Cable, water-tight Cable, metal-free Zero-halogen |
| Cable overall diameter | 8.0 mm |
| Connector type (A) |
SC |
| Polishing plug (A) |
PC |
| Attenuation grade IL (A) | Bm |
| Return loss grade RL (A) | 3 |
| Connector color (A) |
beige |
| Connector type (B) |
SC |
| Polishing plug (B) |
PC |
| Attenuation grade IL (B) | Bm |
| Return loss grade RL (B) | 3 |
| Connector color (B) |
beige |
| Fiber type |
multimode (MM) |
| Fiber class |
OM3 |
| Fiber Count | 12 |
| Conductor type |
loose tube, gel-filled |
| Fiber diameter |
G50 / 125 µm |
| DESCRIPTION | VALUE/VALUE RANGE |
|---|---|
| Cable length | 40.0 m / 131 ft |
| Color |
black |
